Design of DPLL using CMOS Technology

Name: Design of DPLL using CMOS Technology
Brand: LAP Lambert Academic Publishing
SKU: 9786134978156
Price: 33.01 EUR
Availability: InStock

Автор: Shankar N. Dandare, Ankita Deshmukh

Език:

Корици: С меки корици

Издател: LAP Lambert Academic Publishing

Наличност: Външен склад

Изпращаме след 5-8 дни

33.01 € 64.56 лв

PLLs work by continuously adjusting a voltage or current-driven oscillator to match (lock onto) the...

Информация за книгата

Автор

Shankar N. Dandare, Ankita Deshmukh

Език

Английски език

Корици

Книга - С меки корици

Издадена

2018

страници

EAN

9786134978156

Enbook ID

19008957

Издател

LAP Lambert Academic Publishing

Теглоt

125

Размери

150 x 220 x 4

Пълно описание

PLLs work by continuously adjusting a voltage or current-driven oscillator to match (lock onto) the phase and frequency of an input signal. A circuit called a phase comparator causes the VCO to seek and lock onto the desired frequency, which is set via a Voltage Controlled Oscillator. When the VCO frequency differs from the reference frequency, the phase comparator produces an error voltage. Digital Phase locked loop (DPLL) is one of the most important devices in almost all the electronic systems. This book introduces the design of DPLL using sub-micron 45nm CMOS technology and implemented using microwind 3.1 software. The Software microwind 3.1 is used to design and simulate an integrated circuit at physical description level. The performance of DPLL is also observed for the different variable input frequencies and result is observed up to the mark. The lock range for the DPLL and lock time is was also observed as expected.
