Dual Band Microstrip Patch Antenna for WiMAX Application

Name: Dual Band Microstrip Patch Antenna for WiMAX Application
Brand: LAP Lambert Academic Publishing
SKU: 9783846555101
Price: 44.97 EUR
Availability: InStock

Design and Simulation of a Dual Band Microstrip Patch Antenna for WiMAX Application

Автор: Palash Chandra Karmaker, Mohammad Monir Morshed, Md. Ruhul Amin

Език:

Корици: С меки корици

Издател: LAP Lambert Academic Publishing

Наличност: Външен склад

Изпращаме след 5-8 дни

44.97 € 87.95 лв

The design of dual-band microstrip patch antenna based on E-shaped patch for WiMAX (Wireless Interop...

Информация за книгата

Автор

Palash Chandra Karmaker, Mohammad Monir Morshed, Md. Ruhul Amin

Език

Английски език

Корици

Книга - С меки корици

Издадена

2011

страници

116

EAN

9783846555101

Enbook ID

06983044

Издател

LAP Lambert Academic Publishing

Теглоt

189

Размери

150 x 220 x 7

Пълно описание

The design of dual-band microstrip patch antenna based on E-shaped patch for WiMAX (Wireless Interoperability for Microwave Access) application is presented. The proposed antenna is simulated by Electromagnetic simulator, XFDTD (Finite Difference Time Domain Method). The simulation result shows the antenna system resonates at 1.54GHz and 1.97GHz frequencies. These dual band frequencies are suitable for WiMAX applications. The parameters are calculated for outer dimensions of the E-shaped microstrip patch antenna on the basis of line width to substrate thickness (W/h) ratio by considering loss less dielectric material (FR-4 Duroid material). The characteristic line impedance and effective dielectric constant are calculated by considering different values of W/h ratio like 2, 3 and 4. The comparative statement among characteristic line impedance and effective dielectric constant with W/h ratio are presented. This project work also presents how to choose the dimensions of the patch for design a microstrip patch antenna at specific frequency band by a certain dielectric material. The proposed antenna has a centre frequency 2GHz.
